Testing speech recognition with Playwright

While working on my voice-controlled teleprompter app, which was my first experience with speech-related APIs, I discovered a new type of test that’s worse than flaky tests, worse than manual tests, even worse than flaky manual tests.

I’ve discovered the out loud flaky manual test.

The problem

As you’re working, you need to be constantly speaking into the microphone because that’s what you’re testing. This makes people around you constantly wonder if you’re talking to them this time or not, you’re interrupting their work and bringing attention to how you pronounce the word “little”.

The solution

Since we’re already using Playwright, it turns out we can make Chrome listen to our prerecorded voicemail.

Key part are these Chrome flags:

1. --use-fake-ui-for-media-stream
   avoids granting permissions to the microphone
2. --use-fake-device-for-media-stream
   creates a dummy device
3. --use-file-for-fake-audio-capture=path/to/audio.wav
   plays a pre-recorded file on the said fake device
4. --disable-audio-input
   disables any actual microphones you might have so you know you’re listening to the correct (fake) device
5. use channel: "chrome" to refer to Chrome in the Playwright settings to ensure speech recognition API is enabled, using channel: "chromium" (or nothing) will not work as of this writing.

We can now run a test with Playwright in Chrome and, when we start voice recognition (or any microphone-related operation), it will play our WAV file.

The end.

The new problem

But wait, this will play the same WAV file every time, so how do we test different phrases?

What if I need to speak in English and then in Croatian?

The solution #2

What we do is we:

1. create multiple WAV files
2. for each, we create a separate Playwright project
3. ensure the specific test is bound to the specific project and nothing else, since we’ll be asserting exactly what we want to do

This is very tedious to do manually, so let’s engineer a small helper which does it automagically:

1. we put all our WAV files into tests/fixtures, all of them named like speech-<phrase said>.wav

2. for each file we find, we create the already mentioned Playwright project, making sure to tag the project with the file name:

   return {
       name: name,
       use: {
           ...devices["Desktop Chrome"],
           channel: "chrome", // !important
           launchOptions: {
               args: [
                   "--disable-audio-input",
                   "--use-fake-device-for-media-stream",
                   "--use-fake-ui-for-media-stream",
                   `--use-file-for-fake-audio-capture=${filePath}`,
               ],
           },
       },
       // only target tests which have our name as their tag
       grep: new RegExp(`@${name}`),
   };

3. in our test, we tag it with the file name so it only runs in the correct project:

   test(
       "should progress prompter position as speech is recognized",
       // opt-in to a very specific file to use
       { tag: "@speech-hello-world-how-are-you" },
       async ({ page }) => {
           await page.fill("#script-input", "hello world, how are you doing today?");
           await page.locator('[role="speech-control"]').click();
           // wait for the length of the audio file
           await page.waitForTimeout(5000);
           await page.locator('[role="speech-control"]').click();

           const currentWord = await page.locator(".word.current").textContent();
           expect(currentWord).toBe("doing");
       },
   );

4. make sure to exclude the speech-related tests from your “normal” Playwright projects:

    {
        name: "Chrome",
        use: { ...devices["Desktop Chrome"], channel: "chrome" },
        // anything tagged with speech* is skipped in the non-audio projects
        grepInvert: /@speech/,
    },

async function decodeFlacToWav(
    flacPath: string,
    wavPath: string,
): Promise<void> {
    // Skip if WAV exists and is newer than FLAC
    if (existsSync(wavPath)) {
        const flacStat = readFileSync(flacPath);
        const wavStat = readFileSync(wavPath);
        if (wavStat.length > 0) {
            return;
        }
    }

    console.log(`Decoding FLAC to WAV: ${flacPath} -> ${wavPath}`);

    // Read FLAC file
    const flacData = readFileSync(flacPath);

    // Decode FLAC
    const decoder = new FLACDecoder();
    await decoder.ready;

    const decoded = await decoder.decodeFile(flacData);
    decoder.free();

    // Convert Float32Array to Int16Array for 16-bit WAV
    const interleaved = interleaveChannels(decoded.channelData);
    const pcmData = float32ToInt16(interleaved);

    // Create WAV file
    const numChannels = decoded.channelData.length;
    const bitDepth = 16; // Converting to 16-bit
    const dataSize = pcmData.length * 2; // 2 bytes per sample for 16-bit

    const wavHeader = createWavHeader(
        decoded.sampleRate,
        numChannels,
        bitDepth,
        dataSize,
    );

    // Write WAV file
    const wavBuffer = Buffer.concat([wavHeader, Buffer.from(pcmData.buffer)]);
    writeFileSync(wavPath, wavBuffer);

    console.log(`Successfully decoded: ${wavPath}`);
}

Full example of playwright.config.js

async function generateSpeechProjects() {
    const fixturesDir = join(__dirname, "tests/fixtures");

    try {
        const files = readdirSync(fixturesDir);

        // Find all FLAC files and decode them to WAV if needed
        const flacFiles = files.filter((file) => parse(file).ext.toLowerCase() === ".flac");

        for (const flacFile of flacFiles) {
            const { name } = parse(flacFile);
            const flacPath = join(fixturesDir, flacFile);
            const wavPath = join(fixturesDir, `${name}.wav`);

            await decodeFlacToWav(flacPath, wavPath);
        }

        // Now find all WAV files (including newly decoded ones)
        const updatedFiles = readdirSync(fixturesDir);
        const wavFiles = updatedFiles.filter((file) => parse(file).ext.toLowerCase() === ".wav");

        return wavFiles.map((file) => {
            const { name } = parse(file);
            const filePath = join(fixturesDir, file);

            return {
                name: name,
                use: {
                    ...devices["Desktop Chrome"],
                    channel: "chrome",
                    launchOptions: {
                        args: [
                            "--disable-audio-input",
                            "--use-fake-device-for-media-stream",
                            "--use-fake-ui-for-media-stream",
                            `--use-file-for-fake-audio-capture=${filePath}`,
                        ],
                    },
                },
                grep: new RegExp(`@${name}`),
            };
        });
    } catch (error) {
        console.warn(
            `Warning: Could not process fixtures: ${error instanceof Error ? error.message : String(error)}`,
        );
        return [];
    }
}

export default defineConfig({
    projects: [
        // regular tests
        {
            name: "Chrome",
            use: { ...devices["Desktop Chrome"], channel: "chrome" },
            grepInvert: /@speech/,
        },
        // audio tests
        ...(await generateSpeechProjects()),
    ],
});

That’s it, now we’re able to add new speech recognition tests by just adding as many new fixture files as we need and asserting against them.

Bonjour.
